Suzuki’s Innovation
The Suzuki DF175A outboard features a 2,867 cc DOHC 16-valve engine with a 10.2:1 gear ratio.
Its offset driveshaft design enables dual reduction and supports large propellers for maximum propulsion efficiency.
The forward-shifted center of gravity enhances balance, stability, and comfort.
Variable Valve Timing ensures strong performance at all RPM levels.
A counter-balancer reduces vibrations, while the Multi-Stage Induction system optimizes airflow and power delivery.
Corrosion protection, a semi-direct air intake, and advanced sensors guarantee reliability.
The Lean Burn system cuts fuel use and emissions.
The Keyless Start feature and oxygen sensor improve convenience, safety, and environmental performance.
This video was published on the Suzuki Marine Italia YouTube channel.
Plenty more outboard content on this brand of outboards: Catch ’em all.
Specs
| Model | DF175A |
| Recommended transom height | L:508 mm / 20 in, X:635 mm / 25 in |
| Starting system | Electric |
| Weight kg *1 | L:235, X:240 |
| Engine type | DOHC 16-valve |
| Fuel delivery system | Multi-point sequential electronic fuel injection |
| Number of cylinders | In-line 4 |
| Piston displacement | 2,867 cm³ / 174.9 cu.in. |
| Bore × stroke | 97 × 97 mm / 3.81 × 3.81 in |
| Maximum output | 129.0 kW / 175 hp |
| Full throttle operating range | 5,500–6,100 rpm |
| Steering | Remote |
| Oil pan capacity | 8.0 l : 8.5 qt |
| Ignition system | Fully-transistorized |
| Alternator | 12V 44A |
| Engine mounting | Shear mount |
| Trim method | Power trim and tilt |
| Gear ratio | 2.50:1 |
| Gear shift | F-N-R |
| Exhaust | Through prop hub exhaust |
| Propeller selection (pitch) *2 | 3-blade and 4-blade propellers available: 15″-27.5″ (R/R), 17″-26″ (C/R) |
* 1 Dry Weight: Including battery cable, not including propeller and engine oil.
*2 Please inquire at your local dealer for details of the propellers.
