A How-to for DIY
If you’re into DIY mode, this video shows you step by step how to install Mercury SmartCraft® Connect Mobile (website)
It could be interesting for those that need of like real-time engine data, diagnostics and performance insights.
1. Remove the Cowl
Start by removing the engine cowl to access the components underneath.
Locate the 10-pin plug on your engine—on this 90 hp four-stroke, it’s at the front. Though on other models it may be positioned on the side.
Look for the plug labeled “terminator,” which could be yellow, red, or blue.
2. Check the Package
Open the SmartCraft® Connect package and ensure it contains the device, a small bag with zip ties and a screw,. Check the QR code that links to installation instructions and the digital owner’s manual.
3. Prepare the Plug
To prepare the plug, remove any friction-fit shroud to gain better access. Press the black release mechanism on the terminator cap and remove it to expose the pins.
4. Connect the Device
Attach the SmartCraft® Connect device by plugging it into the 10-pin connector until it clicks securely. Keep the terminator cap in a safe place in case you ever need to remove the device.
5. Secure the Device
Secure the device under the cowl using zip ties, ensuring it stays away from moving parts, fuel lines, spark plug wires, and ignition coils.
Replace the shroud if necessary to keep the area neat and protected.
6. Pair with the App
Turn on the engine and download the Mercury Marine app on your mobile device. Create an account, log in, and pair your phone with the SmartCraft® Connect via Bluetooth.
7. Finish Up
Finally, reinstall the cowl. Your installation is complete, and the boat is ready for the water with real-time engine data accessible on your phone.a one-page quick-reference sheet.
This video was published on the Mercury Marine YouTube channel.
