Speed GALA Atlantis A390Q Aquahelm 30 hp Tohatsu

GALA RIBs Are Built in Ukraine

This video demonstrates the speed test of the RIB GALA Atlantis A390Q-Aquahelm. It was powered with a 30 hp Tohatsu and a 14″ pitch prop.

The result was a 53 km/h maximum speed with the use of GPS to register it. With only a 30 hp engine, the results are still great at 29 knots.

It was performed on the lovely Canadian waters of Georgian Bay.

---

This video was published on the GALA INFLATABLE BOATS YouTube channel

Here are more videos of GALA RIBs on RIBsONLY.com.

Specs

Specification	A300Q	A330Q	A360Q	A390Q
Length overall	300 cm / 9’10”	330 cm / 10’10”	360 cm / 11’10”	390 cm / 12’10”
Length inside	222 cm / 7’3″	252 cm / 8’3″	282 cm / 9’3″	310 cm / 10’2″
Width overall	170 cm / 5’7″	170 cm / 5’7″	170 cm / 5’7″	170 cm / 5’7″
Width inside	82 cm / 2’8″	82 cm / 2’8″	82 cm / 2’8″	82 cm / 2’8″
Tube Diameter	44 cm / 17″	44 cm / 17″	44 cm / 17″	44 cm / 17″
Bare boat weight	97 kg / 213 lbs	103 kg / 226 lbs	109 kg / 239 lbs	115 kg / 253 lbs
Loading capacity	500 kg / 1100 lbs	550 kg / 1210 lbs	600 kg / 1320 lbs	650 kg / 1430 lbs
Passenger capacity (Canadian)	4	4	5	5
Passenger capacity iInternational)	5	5	6	6
Number of chambers	3	3	3	3
Engine recommended	10 hp	20 hp	20 hp	20 hp
Maximum engine power	20 hp	30 hp	30 hp	30 hp
Maximum  engine weight	50 kg / 110 lbs	60 kg / 132 lbs	70 kg / 154 lbs	70 kg / 154 lbs
Engine shaft length	15″ (short)	15″ (short)	15″ (short) / 20″ upgrade	15″ (short) / 20″ upgrade
Aluminum hull thickness	2.5 mm / 7/64″	2.5 mm / 7/64″	2.5 mm / 7/64″	3 mm / 1/8″
Boat design category	C*	C*	C*	C*
